- Specification
- Features & Benefits
Product Type
4-WAY Ball Valve Threaded End
Model
VS-V4W
Size Range
1/2” ~ 4”
Operation
Lever Handle
Pressure Rating
1000PSI
Body Material
ASTM A351 CF8M
Port
Full Port
Ball Material
ASTM A351 CF8M
End Connection
Threaded End
Seat Material
PTFE
Designs
Investment Casting Made / Blow-out Proof Stem / Anti-Static device / Direct Mounting Pad ISO 5211 / L port, T port, X port
Stem Material
AISI 316
Options
Locking device
Applications
Process, Pipeline, OEM Equipment
- Multi-Port Flow Versatility featuring configurable L-port, T-port, and X-port patterns, enabling multi-directional routing, continuous line switching, and automated fluid divergence in a single compact unit.
- Maximum Throughput with Zero Restriction engineered with a Full Port flow bore across sizes 1/2” to 4”, preventing system head loss and maintaining optimal line pressure up to a 1000 PSI pressure rating.
- Direct-Mount Automation Ready integrated with an ISO 5211 Direct Mounting Pad, allowing direct installation of pneumatic or electric actuators without external brackets, reducing hysteresis and assembly costs.
- Intrinsically Safe Operation equipped with an AISI 316 blow-out proof stem and an integrated Anti-Static device, ensuring continuous grounding and preventing spark ignition during volatile media transfer.
- Rugged Chemical Compatibility manufactured via precision investment-cast ASTM A351 CF8M stainless steel with high-grade PTFE seats, delivering bubble-tight shut-off and chemical resistance for critical process loops.
This 4WAY multiport stainless steel ball valve from VALTEK (Shanghai), a trusted China valve manufacturer, is ideal for any demanding process or system, offering durability, efficiency, and reliable performance.
